Code Virtualizer Method Swizzling Demo

This project demonstrates Oreans Code Virtualizer protection applied to Objective-C method swizzling on macOS (arm64).

Project Files

Source Files

• swizzle.m - Dynamic library that performs Objective-C method swizzling

  • Protected with Code Virtualizer macros (VIRTUALIZER_START, VIRTUALIZER_END, VIRTUALIZER_STR_ENCRYPT_START, etc.)
  • Includes Stealth Code Area for additional anti-debugging protection

• test_swizzle.m - Test program to verify the swizzling functionality

  • Logs the output to demonstrate the effect of the swizzling

Built Artifacts

• libswizzle_arm64.dylib - Unprotected version of the swizzling library
• libswizzle_arm64_protected.dylib - Protected version (virtualized with Code Virtualizer in Demo mode)
• test_swizzle_arm64 - Compiled test executable

Building

make all

• libswizzle_arm64.dylib : The swizzling dynamic library
• test_swizzle_arm64 : The test executable

Running the Demo

Note: SIP must be disabled to run the demo due to the use of DYLD_INSERT_LIBRARIES for method swizzling.

./scripts/demo_swizzle.sh

Code Virtualizer Protection

The swizzle.m file demonstrates several Code Virtualizer features:

Virtualization Macros

• VIRTUALIZER_START / VIRTUALIZER_END - Marks code sections to be virtualized
• VIRTUALIZER_STR_ENCRYPT_START / VIRTUALIZER_STR_ENCRYPT_END - Encrypts string literals

Note: VIRTUALIZER_STR_ENCRYPT_START is not available in the demo version.

Stealth Code Area

The code includes a stealth area that:

• Provides additional anti-debugging protection
• Makes analysis more difficult
• Uses STEALTH_AREA_START, STEALTH_AREA_CHUNK, STEALTH_AREA_END macros

See docs/logs.logs for available features applied to the demo.
